Tektronix MSO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
5GS/s
Analog bandwidth setting
Input
Frequency
0.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 6.7 bits 6.5 bits 6.6 bits 6.7 bits
510 M Hz 6.7 bits 6.4 bits
2.5 GS/s
Analog bandwidth setting
Input
Frequency
0.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 6.5 bits 6.5 bits 6.6 bits 6.7 bits
510 MHz 6.4 b it
s
6.4 bit
s
Noise, typical
≥ 4GHzm
odels
Without enhanced bandwidth
Gain setting MSO72004C,
DSA72
004C,
DPO72004C
MSO71604C,
DSA71
604C,
DPO71604C
MSO71254C,
DSA71
254C,
DPO71254C
MSO70804,
DSA70
804B,
DPO70804B
MSO70604,
DSA70
604B,
DPO70604B
MSO70404,
DSA70
404B,
DPO70404B
10 mV 0.87
mV
0.87
mV
0.67
mV
0.58
mV
0.53
mV
0.50
mV
15 mV 1.06 mV 1.06 mV 0.84 mV 0.74 mV 0.73 mV 0.69 mV
20 mV 1.21 mV 1.21 mV 0.98 mV 0.90 mV 0.86 mV 0.86 mV
30 m
V
1.8
2mV
1.8
2mV
1.4
9mV
1.3
4mV
1.2
5mV
1.2
5mV
40 mV 2.29 mV 2.29 mV 1.80 mV 1.76 mV 1.67 mV 1.67 mV
50 mV 2.78 mV 2.78 mV 2.29 mV 2.02 mV 2.02 mV 2.02 mV
60
mV
3.
35 mV
3.
35 mV
2.
78 mV
2.
52 mV
2.
46 mV
2.
46 mV
70 mV 3.92 mV 3.92 mV 3.27 mV 3.02 mV 2.90 mV 2.90 mV
80 mV 4.49 mV 4.49 mV 3.76 mV 3.52 mV 3.34 mV 3.34 mV
9
0mV
5
.14 mV
5
.14 mV
4
.25 mV
3
.87 mV
3
.78 mV
3
.78 mV
100 mV 6.48 mV 6.48 mV 4.89 mV 4.50 mV 4.28 mV 4.28 mV
200 mV 11.47 mV 11.47 mV 8.98 mV 8.80 mV 8.36 mV 8.36 mV
250 mV 14.04 mV 14.04mV 11.07mV 10.81mV 10.34mV 10.34mV
300 mV 16.61 mV 16.61mV 13.15mV 12.82mV 12.32mV 12.32mV
400 mV 21.83 mV 21.83 mV 19.01mV 17.36 mV 16.91mV 16.91mV
450 mV 24.41 mV 24.41mV 21.30mV 19.44mV 18.97mV 18.97mV
500 mV 26.99 mV 26.99mV 23.59mV 21.51 mV 21.02 mV 21.02mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–21
