Tektronix MSO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
MSO72004C,
MSO71604C,
MSO71254C,
DSA72004C
,
DSA71604C,
DSA71254C,
DPO72004C
,
DPO71604C,
DPO71254C
where app
licable
12.5GHz 12GHz 11 GHz 10 GHz 9 GHz 8 GHz 7 GHz 6 GHz
Gain set
ting
10 mV 0.55 mV 0.53mV 0.51 mV 0.49 mV 0.46 mV 0.45 mV 0.43 mV 0.40 mV
15 mV 0.72 mV 0.71mV 0.68 mV 0.65 mV 0.63 mV 0.60 mV 0.57 mV 0.54 mV
20 mV 0.82 mV 0.81mV 0.78 mV 0.75 mV 0.71 mV 0.67 mV 0.63 mV 0.60 mV
30 mV 1.24 mV 1.20mV 1.16 mV 1.10 mV 1.03 mV 0.99 mV 0.95 mV 0.89 mV
40 mV 1.55 mV 1.49mV 1.43 mV 1.39 mV 1.33 mV 1.27 mV 1.18 mV 1.10 mV
50 mV 1.80 m
V
1.78m
V
1.72 m
V
1.65 m
V
1.57 m
V
1.48 m
V
1.41 m
V
1.31 m
V
60 mV 2.23 mV 2.18mV 2.12 mV 1.99 mV 1.89 mV 1.79 mV 1.71 mV 1.60 mV
70 mV 2.67 mV 2.58mV 2.51 mV 2.34 mV 2.21 mV 2.11 mV 2.01 mV 1.88 mV
80 mV 3.10
mV
2.98
mV
2.90
mV
2.78
mV
2.61
mV
2.49
mV
2.37
mV
2.25
mV
90 mV 3.35 mV 3.27mV 3.14 mV 3.02 mV 2.86 mV 2.74 mV 2.61 mV 2.45 mV
100 mV 4.09 mV 4.05mV 3.94 mV 3.73 mV 3.55 mV 3.36 mV 3.18 mV 2.99 mV
200
mV
7.7
6mV
7.4
7mV
7.1
6mV
6.9
3mV
6.5
5mV
6.3
3mV
5.9
4mV
5.5
1mV
250 mV 9.37 mV 9.03mV 8.68 mV 8.35 mV 7.92 mV 7.63 mV 7.20 mV 6.68 mV
300 mV 10.98mV 10.58mV 10.19mV 9.76 mV 9.30 mV 8.93 mV 8.46 mV 7.84 mV
40
0mV
15
.16mV
14
.79mV
14
.29mV
13
.60mV
13
.01mV
12
.40mV
11
.81mV
11
.07mV
450 mV 16.88mV 16.47mV 15.93mV 15.12 mV 14.50mV 13.80mV 13.17mV 12.34mV
500 mV 18.60mV 18.15mV 17.56mV 16.65 mV 15.98mV 15.20mV 14.53mV 13.61mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–23
