Pinpoint trigge

5. Select the data format.

6. Set the pattern to trigger on using the

keypad.

7. Analyze your waveforms.

MSO/DPO70000DX, MSO/DPO70000C, DP O7000C, and MS O/DPO5000 Series U ser M anual 79
