Horizontal and acquisition setups Enable fast acquisitions
Behavior
The Autoset Undo window remains open until you click Undo or OK. After the Autoset Undo window
closes, you can still undo the last autoset by selecting Undo Last Autoset from the Edit or Horiz/Acq
menus; the last autoset is immediately undone but the Autoset Undo control window does not open again.
To suppress the AutoSet Undo window following an autoset, do the following:
1. From the Utilities menu, select User Preferences.
2. Open the Prompts tab.
3. Under Prompt user before performing requested action, toggle the Autoset Undo button to Off.
What do you
want to do next?
Learn about Autoset. (see page 185)
Enable fast acquisitions
From the Horiz /Acq menu, select Fast Acquis itions, or press the front panel Fast/Acq button.
Overvi
ew
Use these controls to turn the Fast Acquisition feature on or off and to optimize waveform detail.
To use
1. Click the Fast Acq button to turn Fast Acquisitions On or Off. You will also find this control in the
Acquisitions tab of the Horizontal/Acquisition control window
(see page 181),
2. Click the option boxes to optimize acquisitions for your measurement: Capturing Details with Higher
Sample Rate enhances waveforms detail, Capturing Rare Events with More acquisitions provides
the fastest update rate.
186 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
