Bus setups Select the USB bus signal type

Select the USB bus signal type

NOTE. The USB bus Signal Type is available only on instruments with option SR-USB.

From the Bus Setup window, select Serial from the Bus Type list and then select the USB Serial bus type.

To use

To change the signal type for the displayed components of the bus, click Signal Type and select from

the cascad

ing list.

Behavio

The instrument acquires data from the channel you select for each compone nt.

What do you want to do next?

Learn more about b us setups. (see page 95)

Learn a bout bus conﬁguration. (see page 148)

Learn about digital setups. (see page 87)
