Bus setups Select the data rate
Select the data rate
From the Bus Setup window, select Serial from the Bus Type list and then select the Serial bus type.
To use
To change the data rate for the displayed component of the bus, click Data Rate and select from the
cascading l
ist. Items in the list depend on the serial bus type.
Behavior
The instrument acquires data from the channel you select for each component.
What do you want to do next?
Lear
n more about bus setups.
(see page 95)
Learn about bus configuration. (see page 148)
Learn about digital setups. (see page 87)
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 127
