Performance ver
ification
9. Calculate and record the IF feedthrough spur amplitude in dBc (IF amplitude (dBm) +30).
10. Repeat steps 7 through 9 for each center frequency listed in the table. Do not change the signal generator frequency.
11. Record results in the Test record.
Table 19: 1190 MHz IF feedthrough spurious: RSA306 center frequencies
Center frequenc y, MHz
(RSA306)
IF feedthrough spur
amplitude, dBm
IF feedthrough spur
amplitude, dBc
1
Specificatio
n, dBc
(relative to –30 dBm
input)
3100 MHz < –50 dBc
4000 MHz < –50 dBc
4800 MHz < –50 dBc
5100 MHz < –50 dBc
5900 MHz < –50 dBc
1
IF feedthrough spur amplitude + 30.
2440 MHz
IF feedthrough.
12. Set the signal generator to 2440 MHz.
13. Set the signal generator for -30 dBm at the power meter. This is also the amplitude at the input of the RSA306. The
generator amplitude will be close to -24 dBm.
14. Set the RSA306 to the center frequency shown in the first column of the 2440 MHz IF feedthrough table. (See Table 20
on page 44.)
15. Measure and record IF feedthrough spur amplitude.
16. Calculate and record the IF feedthrough spur amplitude in dBc (IF amplitude (dBm) +30).
17. Repeat steps 14 through 16 for each center frequency listed in the table. Do not change the signal generator frequency.
18. Record results in the Test record.
Table 20: 2440 MHz IF feedthrough spurious: RSA306 center frequencies
Center frequenc y, MHz
(RS
A306)
IF feedthrough spur
amp
litude, dB m
IF feedthrough spur
amp
litude, dB c
1
Specification, dBc
(relative to –30 dBm
inp
ut)
30 MHz < –50 dBc
710 MHz < –50 dBc
42
00 MHz
<–
50 dBc
1
IF feedthrough spur amplitude + 30.
RSA306 Specifications and Performance Verification 44
