Tektronix RSA306 Technical Reference

Performance ver
ification
23. Set the RSA306 to the center frequency shown in the first column of the 2440 MHz half-IF table. (See Table 24
on page 51.)
24. Measure and re
cord the H alf-IF spur amplitude.
25. Calculate and
record the Half-IF spur amplitude in dBc (Half-IF amplitude (dBm) +30).
26. Repeat steps 2
3 through 25 for each center frequency listed in the table.
27. Record resul
ts in the Test record.
Table 24: 2440 MHz half-IF spurious: RSA306 center frequencies
Center frequ ency, MH z
(RSA306)
Half-IF spur amplitude,
dBm
Half-IF spur amplitude,
dBc
1
Specification, dBc
(relative to –30 dBm
input)
30 MHz < –50 dBc
710 MHz < –50 dBc
4200 MHz < –50 dBc
1
Half-IF spur amplitude + 30.
51 RSA306 Speci fications and Performance Verification
