Tektronix RSA5106B Technical Reference

Performance Verification
4. Set the RSA5100
B:
Center Frequency
Setup > Settin
gs > Freq & Span > C enter
1GHz
Span
Setup > Settings > Freq & Span > Span
25 MHz
RBW
Setup > Settings > BW > RBW
1kHz
Function
Setup > Settings > Traces > Function
Avg (RMS)
Averages
Setup > Settings > Traces > Function
25 (count box is checked)
Ref Level
Setup > Amplitude > Ref Level
-15 dBm
Internal Attenuator
Setup > Amplitude > Internal Attenuator
10 dB (Auto unchecked)
5. Set the RF generator:
Output Level
–15 dBm
Output Frequency 1 GHz
RF
On
6. Turn on the Marker Reference (MR) and Marker 1 (M1) and set them for
Delta Operation.
Select Markers located at the bottom right of the screen on the status bar
to display the Markers control bar.
Click the down arrow on the left side of the Markers control bar to view
the Select a Marker dropdown menu. Select Add Marker to add the
MR
marker.
Select Add Marker againtoaddtheM1marker.
Select Define located on the right side of the Markers control bar to open
the Define Markers control panel.
Select Delta from the Readouts dropdown menu.
7. After averaging has completed, select Reference Marker MR using the Select
a Marker dropdown menu on the left side of the Markers control bar.
8. Press the Peak key on the Markers control bar.
9. Select Marker 1 M1 using the Select a Marker dropdown menu on the left
side of the Markers control bar.
RSA5100B Series Technical Reference 129
