Performance Verification
10. Set the M1 marke
r frequency to -12.5 MHz (Option B85: -42.5 MHz, Option
B16x: -55 MHz).
11. Rotate the con
trol knob and verify that all marker amplitudes as shown by the
Delta M1 marker readout are less than -73 dBc from -12.5 MHz (Option B85:
-42.5MHz,OptionB16x:-55MHz)to-400kHzand400kHzto12.5MHz
(Option B85: 42.5 MHz, Option B16x: 55 MHz).
12. (Option B85/B16x only) Set the RSA5100B Span (Setup > Settings > Freq &
Span > Span) to 85 MHz or 160 MHz. Repeat steps 7 to 11.
13. Enter Pass or Fail into the test record.
Spurious Response with
Signal (Half-IF)
1. Connect t
he RF generator to the RSA5100B RF Input.
NOTE. Use a low-pass filter if the RF generator has a 2
nd
harmonic product
greater than -70 dBc.
2. Reset the RSA5100B to factory defaults: select Setup > Preset (Main).
3. Select Tools > Alignments and select Align Now.
4. Set the RSA5100B:
Internal Attenuator
Setup > Amplitude > Internal Settings > Ref Level
10 dB (Auto unchecked)
Ref Level
Setup > Amplitude > Internal Settings > Ref Level
–30 dBm
Span
Setup > Settings > Freq & Span > Span
10 kHz
Function
Setup > Settings > Traces > Function
Avg (VRMS)
Averages
Setup > Settings > Traces > Function
100 (count checked)
5. Set the RF generator:
Output Level
–
30 dBm
(at the end of the cable/filter)
R
F
On
130 RSA5100B Series Technical Reference
