Tektronix RSA5106B Technical Reference

Specifications
Table 39: Views
by domain
Characteristic Description
Frequency, no
minal
Spectrum (Amplitude vs. Frequency)
DPX™ Spectrum Display (Color-Graded Frequency-of-Occurrence)
Spectrogram
(Spectrums over Time vs. Frequency)
Time and Sta
tistics, nominal
Frequency vs. Time
Amplitude v
s. Time
Phase vs. Time
RF I&Q vs. Time
Time Overvi
ew
CCDF
Peak-Average-Ratio
Phase Noise and Jitter Measurements
(Option 11)
Phase Noise
Frequency and Phase Settling
Measure
ments (Option 12)
Frequency Settling
Phase Se
ttling
Noise Fi
gure and Gain Measurements
(Option 14)
Noise Figure
Gain
Noise Temperature
YFactor
Noise T
able
Uncertainty Calculator
Advanced Measurements Suite (Option 20),
nominal
Pulse R
esults Table
Pulse Trace (Selectable by pulse number)
Pulse Statistics (Trend of Pulse Results and FFT of Trend)
General Purpose Digital Modulation Analysis
(Opt
ion 21), nominal
Constellation Diagram
I/Q v
s. Time
EVM vs. Time
Symbol Table (Binary or Hexadecimal)
46 RSA5100B Series Technical Reference

Tektronix RSA5106B Specifications

General

Brand	Tektronix
Model	RSA5106B
Category	Measuring Instruments
Language	English
