Tektronix RSA5106B Technical Reference

Specifications
Table 39: Views by domain (cont.)
Characteristic Description
P25 Analysis (Op tion 26) P25 Constellation
P25 Summary
P25 Eye Diagram
P25 Frequency Deviation vs. Time
P25 Power vs. Time
P25 Symbol Table
Bluetooth A nalysis (Option 27) BT CF Offset and Drift
BT Eye D iagram
BT Constellation
BT Frequency Deviation vs. Time
BT Summary
BT Symbol Table
BT 20dB BW (Tx output spectrum, 20dB bandwidth)
Table 4
0: Noise figure and gain measurements (Option 14)
Characteristic Description
Frequ
ency R ange, nominal
10 MHz to maximum frequency of instrument
Noise
Figure Measurement Range, nominal
0to30
dB
Gain
Measurement Range, nominal
0to30dB
Noi
se Figure and Gain Measurement
Resolution, nominal
0.01 dB
Noi
se Figure Measurement Error, typical
±0.
1dB
1
Ga
in Measurement Error, typical
±0.1 dB
1
1
For (ENR of noise source) > (measured noise figure + 4 dB).
NOTE. Conditions for noise figure and gain specifications: Operating
temperature 18-28°C, after 20 minute. warm up with internal preamp ON,
i
mmediately after internal alignment. Specified error includes only the error of
the spectrum analyzer. Uncertainty from errors in ENR source level, external
amplifier gain, low SN ratio, and measurement system mismatch are not included,
and can all be estimated using the uncertainty calculator included in the software.
RSA5100B Series Technical Reference 47
