Tektronix RSA5106B Technical Reference

Specifications
Table 43: General purpose digital modulation analysis (Option 21) (cont.)
Characteristic Description
Constellation Diagram Display Format,
nominal
Symbol Display,
Frequency Error Measurement,
Origin Offset Measurement
Eye Diagram Display Format, nominal None
Error Vector Diagram Display Format,
nominal
EVM, Magnitude Error, Phase Error,
Waveform Quality () Measurement
Frequency Error Measurement
Origin Offset Measurement
Symbol Table Display Format, nominal
Binary, Hexadecimal
Table 44: Digital demodulation accuracy (Option 21)
Characteristic Description
CF 2 GHz
100 kHz
0.35%
1MHz
0.35%
10 MHz
0.4%
30 MHz
0.75% (Opt.B40/B85/B125/B16x only)
60 MHz
1.0% (Option B85/B125/B16x only)
QPSK
Residual EVM,
typical
Symbol Rate
120 MHz
1.5% (Option B16x only)
CF 2 GHz
10 MHz
0.4%
30 MHz
0.6% (Option B40/B85/B125/B16x only)
60 MHz
0.6% (Option B85/B125/B16x only)
256 QAM
Residual EVM,
typical
Symbol Rate
120 MHz
1.0% (Option B16x only)
CF 2 GHz
100 kHz
0.5%, 200 kHz measurement BW
1MHz
0.5%, 2 MHz measurement BW
Symbol Rate
10 MHz
1.1%, 20 MHz measurement BW
OQPSK
Residual EVM,
typical
Reference Filter: Raised Cosine. Measurement Filter: R oot Raised Cosine. Filter Parameter: Alpha = 0.3
CF
250 MHz
Symbol Rate
4kHz
0.3%, 64 kHz measurement bandwidth
S-OQPSK
(MIL) Residual
EVM, typical
Reference Filter: MIL STD, Measurement Filter: None
CF 2 GHz
20 kHz
0.5%, 320 kHz measurement bandwidth
100 kHz
0.5%, 1.6 MHz measurement bandwidth
1MHz
0.5%, 16 MHz measurement bandwidth
S-OQPSK
(MIL) Residual
EVM, typical
Reference Filter: MIL STD, Measurement Filter: None
RSA5100B Series Technical Reference 49

Tektronix RSA5106B Specifications
