Tektronix RSA5106B Technical Reference

Specifications
Table 44: Digital demodulation accuracy (Option 21) (cont.)
Characteristic Description
CF
250 MHz
Symbol Rate
4kHz
0.3%, 64 kHz measurement bandwidth
S-OQPSK
(ARTM)
Residual EVM,
typical
Reference Filter: ARTM STD, Measurement Filter: None
CF 2 GHz
20 kHz
0.4%, 320 kHz measurement bandwidth
100 kHz
0.4%, 1.6 MHz m easurement bandwidth
Symbol Rate
1MHz
0.4%, 16 MHz measurement bandwidth
S-OQPSK
(ARTM)
Residual EVM,
typical
Reference Filter: ARTM STD, Measurement Filter: None
CF
250 MHz
Symbol Rate
4kHz
0.25%, 64 kHz measurement bandwidth
S-BPSK (MIL)
Residual EVM,
typical
Reference Filter: MIL STD, Measurement Filter: None
CF 2 GHz
20 kHz
0.5%, 320 kHz measurement bandwidth
100 kHz
0.5%, 1.6 MHz m easurement bandwidth
Symbol Rate
1MHz
0.5%, 16 MHz measurement bandwidth
S-BPSK (MIL)
Residual EVM,
typical
Reference Filter: MIL STD, Measurement Filter: None
CF
250 MHz
Symbol Rate
4kHz
0.3%, 64 kHz measurement bandwidth
CPM (MIL)
Residual EVM,
typical
Reference Filter: MIL STD, Measurement Filter: None
CF 2 GHz
20 kHz
0.4%, 64 kHz measurement bandwidth
100 kHz
0.4%, 1.6 MHz m easurement bandwidth
Symbol Rate
1MHz
0.4%, 16 MHz measurement bandwidth
CPM (MIL)
Residual EVM,
typical
Reference Filter: MIL STD, Measurement Filter: None
CF 2 GHz2/4/8/16 FSK
Residual RMS
FSK Error,
typical
Symbol Rate
10 kHz
10 kHz frequency deviation
0.3 % (2FSK)
0.4 % (4/8/16FSK)
Table 45: OFDM measurement (Option 22)
Characteristic Description
OFDM Maximum Residual EVM (RMS)
(802.11a/g/j OFDM and 802.16-2004), typical
–49 dB at 2.4 GHz
–49 dB at 5.8 GHz
50 RSA5100B Series Technical Reference
