Horizontal systems - analog channel
Deskew range +/- 100 ns with 1ns resolution
Horizontal zoom Horizontally expand or compress a live or a stopped waveform
Timebase accuracy 50 ppm
Seconds\Division range 2 ns/div to 100 sec/div in a 1-2-4 sequence.
Signal acquisition system characteristics
No of input channels Two
Input coupling DC or AC
AC coupling connects a capacitor in series with the input circuitry. The DC input impedance
becomes very high, since capacitance is in series with all paths to ground.
Input impedance, DC coupled 1 MΩ, ±2 %
Input capacitance, DC coupled 14pF ± 2pF
Maximum input voltage A300 V RMS, CAT II; derate above 4 MHz at 20 dB per decade to 200 MHz
Number of digitized bits 8 bits
Sensitivity range 1 mV/div to 10V/div in 1-2-5 sequence with probe attenuation set to 1X.
Probe scale factors 1X, 10X, 20X, 50X, 100X, 500X, 1000X voltage attenuation.
5, 1, 500 m, 200 m, 100 m, 20 m, 10 m, 1 m V/A current scale factor.
This adjusts the display scale factor of the instrument to accommodate various probe types.
Accuracy of the probe used must be added to the accuracy specifications of instrument.
No automatic probe interface is provided, so you must verify that the settings match the probe
characteristics. The probe check function allows setting of the proper attenuation for voltage
probes.
Acquisition modes Sample, Peak detect, Average
Retained front panel settings Front panel settings are retained when the instrument power is turned off and on with the power
switch. The settings are retained when the line power is turned off and on.
The instrument periodically saves front panel settings after settings are changed. There is a delay
of three seconds after the last change and before the storage of the settings in memory.
Specifications
2 TBS1000C Series Specification and Performance Verification
