Test record
Table 2: Test record
Instrument Serial Number:
Temperature:
Date of Calibration:
Certificate Number:
RH %:
Technician:
Instrument performance test Minimum Incoming Outgoing Maximum
Channel 1
DC Gain Accuracy
5 mV/div 33.6 mV 36.4 mV
200 mV/div 1.358 V 1.442 V
2 V/div 13.58 V 14.42 V
Channel 2
DC Gain Accuracy
5 mV/div 33.6 mV 36.4 mV
200 mV/div 1.358 V 1.442 V
2 V/div 13.58 V 14.42 V
Channel 1 Bandwidth 2.12 V —
1
Channel 2 Bandwidth 2.12 V —
1
Sample Rate and Delay Time Accuracy -2 divs +2 divs
Channel 1 Edge Trigger Sensitivity Stable trigger —
2
Channel 2 Edge Trigger Sensitivity Stable trigger —
2
Aux In Edge Trigger Sensitivity Stable trigger —
2
Channel 1 Vertical Position Accuracy,
Minimum margin
0 —
Channel 2 Vertical Position Accuracy,
Minimum margin
0 —
1
The bandwidth test does not have a high limit.
2
The limits vary by model. Check the procedure for the correct limits.
Performance verification
14 TBS1000C Series Specification and Performance Verification
