3. Connect the probe tip and ground lead to the PROBE COMP connectors on
the oscilloscope. The probe tip connects to the 5 V connector, and the ground
clip connects to the ground connector.
4. Push Default Setup.
5. Push the Vertical Menu button for the channel to which the probe is
connected, to display that channel.
Getting acquainted with the oscilloscope
TBS2000B Series Oscilloscopes User Manual 29
