7. Use the Multipurpose knob and side-menu buttons to enter the new

password to confirm it.

8. Push OK side-menu button.

NOTE. The cursor password can be changed using the PI commands. Refer to

Programmer manual for detailed instructions.

Analyzing a waveform

TBS2000B Series Oscilloscopes User Manual 109
