How to enable/disable Autoset in the oscilloscope

Use this procedure to enable/disable the Autoset function to set up a waveform

manually.

NOTE. To disable or enable the Autoset function requires a password. The default

factory password is 000000.

1. Push Utility.

2. Push -More- Page 1/2 side-menu button.

3. Push Feature Enable side-menu button.

Acquisition setup

70 TBS2000B Series Oscilloscopes User Manual
