5. For waveform files: Use the Save/Rec side-menu buttons to select the signal

source for saving waveforms (CH1-CH4, Math, Ref1-2).

6. Push the Save button to confirm that the assigned file type and format was

saved to the USB drive.

NOTE. The Assign To button does not store the current save settings (such as file

format or waveform source). The Save button uses the settings of the Save/Rec

side menu to save files.

Saving data

134 TBS2000B Series Oscilloscopes User Manual
