9. Push Recall side-menu button. The oscilloscope loads the waveform data

into the selected reference memory.

NOTE. If the Recall side-menu button shows No file, then you have not

selected an .ISF file.

Recalling data

TBS2000B Series Oscilloscopes User Manual 137
