5. The Wi-Fi icon indicates when a Wi-Fi transceiver dongle is connected to the
oscilloscope.
6. The Network icon indicates when the oscilloscope is connected to a local
area network (LAN).
7. The File Save icon indicates when the oscilloscope send a file to the USB
drive.
8. The Help Everywhere icon indicates when the Help Everywhere function is
enabled to display information on oscilloscope settings when you open a
menu.
9. The trigger level icon shows the trigger level of the active (selected)
waveform. Use the Trigger Level knob to adjust the trigger level. The trigger
level value is shown in the horizontal and trigger readouts at the bottom of
the screen.
Appendices
TBS2000B Series Oscilloscopes User Manual 187
