8. Verify that the installed license was added to the Installed Options list.

9. Repeat steps 5 through 8 for each upgrade license file that you purchased and

downloaded.

For more information on upgrade options, see the Tektronix Web site ( https://

www.tek.com/oscilloscope/tbs2000b-basic-oscilloscope).

Upgrade license

TBS2000B Series Oscilloscopes User Manual 7
