Tektronix TDS 200-Series Service Manual

Adjustment Procedures
5–8
TDS 200 Series Digital Oscilloscope Service Manual
Table 5–3:
TDS 224 Adjustment steps (cont.)
Step Equipment setup Signal source setting Input
31 Sinewave Generator, 50 Ohm 5 kHz, 1 V
p-p
CH1
32 Sinewave Generator, 50 Ohm 1 MHz, 1 V
p-p
33 Sinewave Generator, 50 Ohm 50 kHz, 1 V
p-p
34 Sinewave Generator, 50 Ohm 20 MHz, 1 V
p-p
35 Sinewave Generator, 50 Ohm 100 MHz, 1 V
p-p
36 Sinewave Generator, 50 Ohm 5 kHz, 2.5 V
p-p
37 Sinewave Generator, 50 Ohm 1 MHz, 2.5 V
p-p
38 Sinewave Generator, 50 Ohm 50 kHz, 2.5 V
p-p
39 Sinewave Generator, 50 Ohm 20 MHz, 2.5 V
p-p
40 Sinewave Generator, 50 Ohm 100 MHz, 2.5 V
p-p
41 Sinewave Generator, 50 Ohm 77.133 MHz, 1 V
p-p
42 Edge, 50 Ohm 1 kHz, 0 to –800 mV
43 Sinewave Generator, 50 Ohm 5 kHz, 1 V
p-p
CH2
44 Sinewave Generator, 50 Ohm 1 MHz, 1 V
p-p
45 Sinewave Generator, 50 Ohm 50 kHz, 1 V
p-p
46 Sinewave Generator, 50 Ohm 20 MHz, 1 V
p-p
47 Sinewave Generator, 50 Ohm 100 MHz, 1 V
p-p
48 Sinewave Generator, 50 Ohm 5 kHz, 2.5 V
p-p
49 Sinewave Generator, 50 Ohm 1 MHz, 2.5 V
p-p
50 Sinewave Generator, 50 Ohm 50 kHz, 2.5 V
p-p
51 Sinewave Generator, 50 Ohm 20 MHz, 2.5 V
p-p
52 Sinewave Generator, 50 Ohm 100 MHz, 2.5 V
p-p
53 Sinewave Generator, 50 Ohm 5 kHz, 1 V
p-p
CH3
54 Sinewave Generator, 50 Ohm 1 MHz, 1 V
p-p
55 Sinewave Generator, 50 Ohm 50 kHz, 1 V
p-p
56 Sinewave Generator, 50 Ohm 20 MHz, 1 V
p-p
57 Sinewave Generator, 50 Ohm 100 MHz, 1 V
p-p
58 Sinewave Generator, 50 Ohm 5 kHz, 2.5 V
p-p
59 Sinewave Generator, 50 Ohm 1 MHz, 2.5 V
p-p
60 Sinewave Generator, 50 Ohm 50 kHz, 2.5 V
p-p
61 Sinewave Generator, 50 Ohm 20 MHz, 2.5 V
p-p
62 Sinewave Generator, 50 Ohm 100 MHz, 2.5 V
p-p
63 Sinewave Generator, 50 Ohm 77.133 MHz, 1 V
p-p
64 Edge, 50 Ohm 1 kHz, 0 to –800 mV
