Tektronix TDS 200-Series Service Manual

Adjustment Procedures
TDS 200 Series Digital Oscilloscope Service Manual
5–9
Table 5–3:
TDS 224 Adjustment steps (cont.)
Step Equipment setup Signal source setting Input
65 Sinewave Generator, 50 Ohm 5 kHz, 1 V
p-p
CH4
66 Sinewave Generator, 50 Ohm 1 MHz, 1 V
p-p
67 Sinewave Generator, 50 Ohm 50 kHz, 1 V
p-p
68 Sinewave Generator, 50 Ohm 20 MHz, 1 V
p-p
69 Sinewave Generator, 50 Ohm 100 MHz, 1 V
p-p
70 Sinewave Generator, 50 Ohm 5 kHz, 2.5 V
p-p
71 Sinewave Generator, 50 Ohm 1 MHz, 2.5 V
p-p
72 Sinewave Generator, 50 Ohm 50 kHz, 2.5 V
p-p
73 Sinewave Generator, 50 Ohm 20 MHz, 2.5 V
p-p
74 Sinewave Generator, 50 Ohm 100 MHz, 2.5 V
p-p
