Tektronix TDS 200-Series Instructions

TDS2CM Communications Module
12
TDS 200-Series Extension Module Instructions
Selecting an RS-232 Cable
You will need an RS-232 cable to connect the oscilloscope to an
external device. Use the following table to choose the correct cable
to connect the module to your RS-232 equipment.
To connect the
oscilloscope to
You need this type cable
Tektronix
part number
PC/AT or laptop
computers
9-pin female to 9-pin female,
null modem
012-1379-00
PCs with 25-pin serial
port connector
9-pin female to 25-pin fe-
male, null modem
012-1380-00
Serial printers, such as
an HP Deskjet, and Sun
workstations
9-pin female to 25-pin male,
null modem
012-1298-00
Telephone modems 9-pin female to 25-pin male,
modem
012-1241-00
