Displaying the FFT Waveform
Push the MATH button to display the math menu. Use the menu
buttons to select the FFT source channel, window algorithm, and
display magnification. You can display only one FFT waveform at a
time.
Menu Settings Comments
MATH CH1+CH2 Displays sum of channel 1 and 2 signals
(refer to Changed Math Operations on
page 28)
FFT CH1 Switches between the channel 1 FFT and
YT waveforms (selected = FFT)
FFT CH2 Switches between the channel 2 FFT and
YT waveforms (selected = FFT)
Window Selects the FFT window type
(Hanning, Flattop, Rectangular)
FFT Zoom Changes the horizontal magnification of
the FFT display (X1, X2, X5, X10)
