Remote Communication
3–98
TDS 420A, TDS 430A, TDS 460A & TDS 510A User Manual
Hardcopy (Talk Only) configures the port for hardcopy output without controller
supervision. Once the port is configured this way, the oscilloscope will send the
hardcopy data to any listeners on the bus when the HARDCOPY button is
pressed.
If the port is configured any other way when the HARDCOPY button is pressed,
the digitizing oscilloscope displays a message saying the selected hardcopy port
is unavailable.
Off Bus disconnects the digitizing oscilloscope from the bus.
GPIB Configuration Menu
Figure 3–52: Utility Menu
