Operating Information

TDS1000 and TDS2000 Series Digital Storage Oscilloscopes Service Manual

2-- 9

The DEFAULT SETUP button does not reset the following:

H Language option

H Saved setup files

H Saved reference waveform files

H Display contrast

H Calibration data

H Printer setup

H RS-232 setup

H GPIB setup
