General| Channels | 4 |
|---|---|
| Bandwidth | 100 MHz |
| Sample Rate | 1 GS/s |
| Record Length | 2.5k points |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 2 mV/div to 5 V/div |
| Timebase Range | 5 ns/div to 50 s/div |
| Display Resolution | 320 x 240 pixels |
| Display | 5.7 inch color LCD |
| Trigger Types | Edge, Video |
| Interface | USB |
| Input Impedance | 1 MΩ |
| Power Requirements | 100 to 240 V |
