Specifications
TDS1000 and TDS2000 S eries Digital Storage Oscilloscopes Service Manual
1-7
Table 1- 1: Oscilloscope specifications (Cont.)
Trigger Frequency Counter
Signal Source Pulse Width or Edge Trigger modes: all available trigger sources
The Frequency Counter measures trigger source at all times, including when the oscilloscope acquisition is
halted due to changes in the run status, or acquisition of a single shot event has completed.
Pulse Width Trigger mode: The oscilloscope counts pulses of signifi cant magnitude inside t he 250 ms
measurement window that qualify as triggerable events, such as narrow pulses in a PW M pulse train if set to <
mode and the width is set to a relatively small time.
Edge Trigger mode: The oscilloscope counts all edges of sufficient magnitude and correct pol ari ty.
Video Trigger mode: The Frequency Counter does not operate.
Measurements
Cursors Voltage di ff erence between cursors (ΔV)
Time diff erence between cursors (ΔT)
Reciprocal of ΔTinHertz(1/ΔT)
Automatic Measure-
ments
Frequency, Period, Mean, Pk-Pk, Cycle RMS, Min, Max, Rise Time, Fall Time, Pos Width, Neg Wi dth
Table 1- 2: Oscilloscope general specifications
Display
Display Type 145 mm (5.7 in) diagonal liquid crystal
Display Resolution 320 horizont al by 240 vertical pixels
Display Contrast Adjustable, temperature compensated
Backlight Intensity, typical 65 cd/m
2
Probe Compensator Output
Output Voltage, typical 5Vinto≥ 1MΩ load
Frequency, t ypical 1 kHz
Power Source
Source Voltage 100 -- 120 VAC
RMS
( 10%) from 45 Hz through 440 Hz, CAT II
120 -- 240 VAC
RMS
( 10%) from 45 Hz through 66 Hz, CAT II
Power Consumption Less than 30 W
Fuse 1 A, T rating, 250 V
