Performance Verification
4-2
TDS1000 and TDS2000 S eries Digital Storage Oscilloscopes Service Manual
Test Record
Serial
number
Procedure performed by Date
Test Passed Failed
Self Test
Oscilloscope tests Low limit Test result High limit
Channel 1 DC Gain Accuracy 5mV/div 33.6 mV 36.4 mV
200 mV/div 1.358 V 1.442 V
2V/div 13.58 V 14.42 V
Channel 2 DC Gain Accuracy 5mV/div 33.6 mV 36.4 mV
200 mV/div 1.358 V 1.442 V
2V/div 13.58 V 14.42 V
Channel 3 DC Gain Accuracy
1
5mV/div 33.6 mV 36.4 mV
200 mV/div 1.358 V 1.442 V
2V/div 13.58 V 14.42 V
Channel 4 DC Gain Accuracy
1
5mV/div 33.6 mV 36.4 mV
200 mV/div 1.358 V 1.442 V
2V/div 13.58 V 14.42 V
Channel 1 Bandwidth 2.12 V —
Channel 2 Bandwidth 2.12 V —
Channel 3 Bandwidth
1
2.12 V —
Channel 4 Bandwidth
1
2.12 V —
Sample Rate and Delay Time Accuracy -- 2 d i v s +2 divs
Channel 1 Edge Trigger Sensitivity Stable trigger —
Channel 2 Edge Trigger Sensitivity Stable trigger —
Channel 3 Edge Trigger Sensitivity
1
Stable trigger —
Channel 4 Edge Trigger Sensitivity
1
Stable trigger —
External Edge Trigger Sensitivity Stable trigger —
1
Channels 3 and 4 are only on four channel oscilloscopes.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
