Tektronix TDS2024 Manual

Maintenance
6-- 6
TDS1000 and TDS2000 Series Digital Storage Oscilloscopes Service Manual
Complete disassembly is best achieved by following the procedures in the order
given in Table 6--2 .
Table 6--2: List of procedures
Procedure Begins on page
Rear Feet 6--7
Flip Feet 6--9
Front-Panel Knobs 6--10
Power Button 6--10
Rear Case 6--10
Front Feet 6--14
Power Supply Module 6--15
Internal Assembly 6--17
Display Cable 6--19
Front-Panel Cable 6--21
Main Board Module 6--22
Display Module 6--24
Front-Panel Module 6--26
Keypad 6--28
Front Case 6--30
Use the following tools to remove and replace all modules in the oscilloscope:
H Torque-limiting screwdriver, long shank, 12 in-lb (1.3 N
⋅m) range with
Torx® T-15 tip
H 9/16 inch deep socket with wide center hole (S
⋅K Hand Tool Corp., S-K
#40818, or equivalent)
H Torque wrench to 40 in-lb (4.5 N
⋅m)
H Screwdriver with 1/4 inch flat blade
H Pliers (all-purpose and needle-nose)
H Sharp knife (X-ACTO
® knife or equivalent)
Summary of Procedures
Required Tools

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
