Specifications
1-8
TDS1000 and TDS2000 S eries Digital Storage Oscilloscopes Service Manual
Table 1- 2:
Oscilloscope general specifications (Cont.)
Environmental
Temperature Operating 0 °Cto+50°C(32°F to 122 °F)
Nonoperating -- 4 0 °Cto+71°C(--40°F to 159.8 °F)
Cooling Method Convection
Humidity +40 °C or below
(+104 °F or below)
≤ 90% relative humidity
+41° Cto+50° C
(106 °F to 122 °F)
≤ 60% relative humidity
Altitude Operating and Nonoperating 3,000 m (10,000 ft)
Random Vibrati on Operating 0.31 g
RMS
from 5 Hz to 500 Hz, 10 minutes on each axis
Nonoperating 2.46 g
RMS
from 5 Hz to 500 Hz, 10 minutes on each axis
Mechanical Shock Operating 50 g, 11 ms, half sine
Mechanical
Size Height 151.4 mm (5.96 in)
Width 323.8 mm (12.75 in)
Depth 124.5 m m (4.90 in)
Weight (approxim ate) When packaged for domestic shipment 3.6kg(8.0lbs)
Certifications and Compliances
EN 61326. EMC requirements for Class A electrical equipment for measurement,
control, and laboratory use. Annex D.
H IEC 61000--4--2. Electrostatic discharge immunity
H IEC 61000--4--3. R F electromagnetic field immunity
H IEC 61000--4--4. Electrical fast transient / burst immunity
H IEC 61000--4--5. Power line surge immunity
H IEC 61000--4--6. Conducted RF Immunity
H IEC 61000--4--11. Voltage dips and interruptions immunity
EN 61000- 3- 2. AC power line harmonic emissions
1
EN 61000- 3- 3. Voltage changes, fluctuations, and flicker
1
Emissions which exceed the levels required by this standard may occur when this
equipment is connected to a test object.
