Appendix A: Specifications
A-10
TDS3000B Serie s User Manual
Specifications (cont.)
Power sources
AC line power Operates the oscilloscope and charges the optional internal
battery
Source voltage 90 V
RMS
to 250 V
RMS
, continuous range
Source frequency 47 Hz to 440 Hz
Power consumption 75 W maximum
Battery power Optional accessory TDS3BATB, rechargeable Li-Ion battery pack
Operating time,
typical
3 hours, depending on operating conditions
Battery charge time,
typical
30 hours in the oscilloscope, 5 hours in the optional external
charger TDS3CHG
Line fuse Internal, not user replaceable
Environmental
Temperature Operating range (no disk installed): +5 °Cto+50°C
Nonoperating range (no disk installed): --20 °Cto+60°C
Typical operating range for floppy disks: +10 °Cto+50°C
Humidity Operating range (no disk installed): 20% to 80% RH below
32 °C, derate upper limit to 21% RH at 50 °C
Nonoperating range (no disk installed): 5% to 90% RH below
41 °C, derate upper limit to 30% RH at 60 °C
Typical operating range for floppy disks: 20% to 80% RH below
32 °C, derate upper limit to 21% RH at 50 °C
Pollution Degree Pollution Degree 2: Typical home or office environment
