Getting Started
1-18
TDS3000B Serie s User Manual
Installing a Communication Module
CAUTION. To avoid damage to the oscilloscope or communication
module, observe the ESD precautions described on page viii.
To install one of the optional com munications modules, do these
steps:
1. Turn the oscilloscope power off.
2. Press down on the latching tab to remove the blank cover.
3. Slide the communication module into the compartment unt il the
internal connectors are seated and the l atching tab locks.
4. Turn power on. The communication module is now ready for
your use.
To rem ove a communication module, do these steps:
1. Turn the oscilloscope power off.
2. Press down on the latchi ng ta b and then use a small screwdriver
to al ternately pry out the sides of the communi cation module.
3. Slide out the communication module and store it i n an ESD-
shielded bag. Install the blank cover if no othe r communication
module is to be installed.
Communication module port For more information, see
GPIB Hard Copy on page 3--27 of this
manual and the TDS3000 &
RS-232
TDS3000B Series Programmer
Manual
VGA Page A--9 in this manual
To Next Page
