Tektronix TDS3032B User Manual

Appendix B: Factory Setup
B-2
TDS3000B Serie s User Manual
Control Changed by factory setup to
Cursor V Bar 1 position 10% of record
Cursor V Bar 2 position 90% of record
Cursor V Bar units Seconds
Cursor tracking Independent
Delay measure from waveform edge Rising
Delay measure to edge occurrence First
Delay measure to waveform Ch 1
Delay measure to waveform edge Rising
Display graticule type Full
Display backlight High
Display color palette Normal
Display dots only Off
Display persist time Auto
Dual waveform math function Ch1+Ch2
Edge trigger coupling DC
Edge trigger level 0.0 V
Edge trigger slope Rising
Edge trigger source Channel 1
External trigger probe setup
(four-channel models only)
Voltage, 1X
Horizontal delay On
