Getting Started
1-30
TDS3000B Serie s User Manual
1. Edge Trigger cont rols. Push these screen buttons to set trigger
parameters for edge trigger.
2. Trigger controls if either B trigger or video trigger is selected.
3. Cursor control. Push this screen button to turn on cursors and
select the cursor type. Push the SELECT button to t oggl e
between the two cursors to select the active cursor. Use the
general purpose knob to move the ac tive cursor.
4. Acquisition controls. Push these screen buttons to set acquisition
parameters.
5. Channel vert ical controls. Push these screen buttons t o set
vertical controls for the select ed channel. Use the CH1, CH2,
CH3, CH4, MATH, and REF buttons t o select the cha nnel you
want to control.
6. Vertical controls if either the math waveform or a reference
waveform is selected.
7. Menu. Push this screen button to select a specific QuickMenu
display i f more tha n one is available.
NOTE. Items in the Scope Quick Menu not mentioned above are also
contained in the regul ar display. Those it ems are described on
page 1--27.
Other QuickMenus. Some optional application packages include a
custom QuickMenu displa y. Those QuickMenus c ontain specific
features that are important for the applic ation.
