Acquisition Controls

TDS3000B Serie s User Manual

3-11

If you probe a noisy square wave signal that contains intermittent,

narrow glitches, the waveform displayed will vary depending on the

acquisition mode you choose.

Sample Peak Detect

Envelope Average

Table of Contents5
