Operating Information
2-4
TDS3000B Series Service Manual
To install the optional battery pack, do t hese steps:
1. Open the battery compartment door on the rear panel and remove the
accessory tray.
Battery door
2. Slide the battery into the compartment and press it in from both sides until
you hear the latches click.
3. Press on both sides of the battery compartment door to snap it closed.
Installing and Removing
the Battery
