Operating Information
TDS3000B Series Service Manual
2-23
Transporting the Oscilloscope
When transporting the oscilloscope, wrap the cord around the handle as shown
below. Use the supplied cord retainer i f the power plug does not have a
molded-in retainer. The oscilloscope front cover has a convenient place to store
TDS3000B Series 1/4-size user and reference manuals.
If you are not using a battery, you can use the accessory tray in the battery
compartment to store probes and other accessories.
CAUTION. To avoid damage to the disk drive, do not transport the oscilloscope
with a floppy disk in the disk drive.
