Appendix A: Specifications
A-20
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
Table A- 3: Horizontal and acquisition system specifications (Cont.)
Characteristic Description
Maximum record length, HiRes mode, sample
rate ≤1.25 GS/s
CSA7404, CSA7154, TDS7404, TDS7254, &
TDS7154
2,000,000 points (1, 2, 3, or 4 channels)
Seconds/division range
CSA7404, CSA7154,
TDS7404, TDS7254,TDS7154,
TDS6604, & TDS6404
50 ps/div to 10 s/div
TDS7104 & TDS7054 200 ps/di v to 40 s/div
Maximum FastFrame update rate, nominal
CSA7404, CSA7154, TDS7404, TDS7254,
TDS7154, TDS7104, & TDS7054
160,000 frames per second
