Tektronix TDS7054 User Manual

Appendix A: Specifications
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
A-37
Table A- 9: Power source specifications
Characteristic Description
Power consumption
CSA7404, CSA7154,
TDS7404, TDS7254, TDS7154,
TDS7104 & TDS7054
≤600 Watts (900 VA)
TDS6604, & TDS6404 ≤400 Watts (400 VA)
Source voltage and frequency 100 to 240 V 10%,50Hzto60Hz
115 V 10%, 400 Hz
CAT II
Fuse rating Either one of the fol lowing sizes can be used, each size requires a different fuse
cap. Both fuses must be the same type.
0.25 in × 1.25 in size UL198G and CSA C22.2, No. 59, fast acting: 8 A, 250 V
(Tektronix part number 159-0046-00, Bussman ABC-8, Littelfuse 314008)
5mm× 20 mm size IEC127, sheet 1, fast acting “F”, high breaking capacity: 6.3 A, 250 V (Bussman
GDA 6.3, Littelfuse 21606.3)
Table A- 10: Mechanical specifications
Characteristic Description
Weight
Benchtop configuration
CSA7404, CSA7154,
TDS7404, TDS7254, TDS7154,
TDS7104, & TDS7054
17.7 kg (39 lbs) instrument only
19.1 kg (42 lbs) with fully accessorized pouch
38.8 kg (85.5 lbs) when packaged for domestic shipment
TDS6604, & TDS6404 15 kg (33 lbs) with fully accessorized pouch
24 kg (53 lbs) when packaged for domestic shipment
Rackmount kit
CSA7404, CSA7154,
TDS7404, TDS7254, & TDS7154
TDS6604, & TDS6404
TDS7104, & TDS7054
18.6 kg (41 lbs) rackmounted instrument
5.6 kg (12.5 lbs) ki t packaged for domestic shipment
5 lbs (2.3 kg) rackmount conversion kit
8 lbs (3.6 kg) kit packaged for domestic shipment
