CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
3- 147
Measuring Waveforms
The instrument comes equipped with cursors and automatic measurements to
assist you in analyzing your waveforms. This section describes these tools and
how you use them:
H Taking Automatic Measurements, on page 3--148, describes how you can
setup the instrument to automatically measure and display a variety of
waveform parameters. See Figure 3--33.
H Taking Cursor Measurements, on page 3--160, describes using cursors to
make measurements on waveforms. See Figure 3--33.
H Taking Histograms, on page 3--168, describes how to take histograms to
view the horizontal or vertical distribution of data on your waveforms.
H Optimizing Measurement Accuracy, on page 3--171, tells you how to run
compensation routines and how to deskew channels to optimize the accuracy
of your measurements.
NOTE. You can also make graticule measurements, counting graticule divisions
and multiplying them by the vertical or horizontal scales set for the waveform
that you are measuring.
