Tektronix TDS7054 User Manual

2-10
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
Front Panel I/O Map
Auxiliary trigger input
Auxiliary trigger output
CH 3 SIGNAL OUTPUT; scale and
offset controlled by CH3 controls
Probe
compensation
output
Ground terminal
Channel
inputs
Auxiliary trigger input
Auxiliary trigger output
CH 3 SIGNAL OUTPUT; scale and
offset controlled by CH3 controls
Probe compensation
output
Ground terminal
Channel
inputs
TDS7404, TDS7254, TDS7154, TDS6604, & TDS6404
Floppy disk drive
Recovered clock output
Optical input
O/E converter electrical output
Probe compensation
output
Ground terminal
Channel
inputs
Recovered data output
CSA7000 Series
TDS7104 & TDS7054
