Removal and Installation Procedures
TDS7104 & TDS7054 Service Manual
6-- 31
1. Locate module to be removed: Locate the Hard Disk Drive in the locator
diagram Internal Modules, Figure 6--8, on page 6--19.
CAUTION. Do not remove the replaceable hard disk drive when the oscilloscope
is powered on.
The replaceable hard disk drive may be permanently damaged if it is removed
while the oscilloscope is powered on.
Always power down the oscilloscope before removing the replaceable hard disk
drive.
2. Orient the oscilloscope: Set the oscilloscope so its bottom is down on the
work surface and its rear panel is facing you.
3. Remove the hard disk drive: See Figure 6--18, on page 6--32.
a. Verify that the oscilloscope is powered off.
b. Push the hard disk drive cover in and the hard drive will disconnect from
the latch.
c. Grasp the hard disk drive assembly and slide it out of the oscilloscope.
4. Reinstallation: Do in reverse step 3 to reinstall the hard disk drive assembly.
The hard disk drive will push in to lock and push in again to unlock.
Hard Disk Drive
