Tektronix WFM7020 User Manual

Getting Acquain
tedWithYourInstrument
10 ANALO G_INP
UT_B5_P
Balanced diff
erential analog audio input- Ch. 5, line B, positive.
11 ANALOG_INP
UT_A6_P
Balanced diff
erential analog audio input- Ch. 6, line A, positive.
12 ANALO G_IN
PUT_B6_P
Balanced dif
ferential analog audio input- Ch. 6, line B, positive.
13 GND
14 ANALOG_O
UTPUT_1_P
Balanced di
fferential analog audio output- Ch. 1, positive.
15 ANALOG_
OUTPUT_2_P
Balanced d
ifferential analog audio output- Ch. 2, positive.
16 ANALOG_
OUTPUT_3_P
Balanced d
ifferential analog audio output- Ch. 3, positive.
17 ANALOG
_OUTPUT_4_P
Balanced
differential analog audio output- Ch. 4, positive.
18 ANALO
G_OUTPUT_5_P
Balance
d differential analog audio output- Ch. 5, positive.
19 ANALO
G_OUTPUT_6_P
Balance
d differential analog audio output- Ch. 6, positive.
20 ANAL
OG_OUTPUT_7_P
Balanc
ed differential analog audio output- Ch. 7, positive.
21 ANAL
OG_OUTPUT_8_P
Balanc
ed differential analog audio output- Ch. 8, positive.
22 ANA
LOG_INPUT_A1_N
Balan
ced differential analog audio input- Ch. 1, line A, negative.
23 AN
ALOG_INPUT_B1_N
Bala
nced differential analog audio input- Ch. 1, line B, negative.
24 AN
ALOG_INPUT_A2_N
Bala
nced differential analog audio input- Ch. 2, line A, negative.
25 A
NALOG_INPUT_B2_N
Bal
anced differential analog audio input- Ch. 2, line B, negative.
26 A
NALOG_INPUT_A3_N
Bal
anced differential analog audio input- Ch. 3, line A, negative.
27
ANALOG_INPUT_B3_N
Ba
lanced differential analog audio input- Ch. 3, line B, negative.
28
ANALOG_INPUT_A4_N
Ba
lanced differential analog audio input- Ch. 4, line A, negative.
2
9 ANALOG_INP UT_B4_N
B
alanced differential analog audio input- Ch. 4, line B, negative.
30 ANALOG _INP UT_A5_N Balanced differential analog audio input- Ch. 5, line A, negative.
31 ANALOG _INP UT_B5_N Balanced differential analog audio input- Ch. 5, line B, negative.
32 ANALOG _INP UT_A6_N Balanced differential analog audio input- Ch. 6, line A, negative.
33 ANALOG _INP UT_B6_N Balanced differential analog audio input- Ch. 6, line B, negative.
34 GND
35 ANALOG_OUTPUT_1_N Balanced differential analog audio output- Ch. 1, negative.
36 ANALOG_OUTPUT_2_N Balanced differential analog audio output- Ch. 2, negative.
37 ANALOG_OUTPUT_3_N Balanced differential analog audio output- Ch. 3, negative.
38 ANALOG_OUTPUT_4_N Balanced differential analog audio output- Ch. 4, negative.
39 ANALOG_OUTPUT_5_N Balanced differential analog audio output- Ch. 5, negative.
40 ANALOG_OUTPUT_6_N Balanced differential analog audio output- Ch. 6, negative.
41 ANALOG_OUTPUT_7_N Balanced differential analog audio output- Ch. 7, negative.
42 ANALOG_OUTPUT_8_N Balanced differential analog audio output- Ch. 8, negative.
43—62 No connection.
