Preface
Feature Description
Surround Sound display of audio signals and phase relationships of normal channel
pairs.
Lissajous disp
lay lets y ou monitor a user-specified pairing of channel inputs.
Support and op
tions for viewing and monitoring both levels of normal channel pairs
for AES, analog, embedded audio, and Dolby signals (Dolby support available with
the WVR6020 and WVR7120, only).
Audio monitoring
Loudness measurement, audio control packet coding, and many popular audio
scales, including BBC scales, are also supported.
Ancillary data monitoring
Support for monitoring ancillary data including data conforming to ARIB standards
and EIA 608 Ex
tended Data Services (XDS).
Closed Capti
oning support
Support for d
ecode and display of CC standards (EIA 608 (VBI), EIA 608 (ANC),
EIA (608/708), EIA 708, TeletextB (VBI), TeletextB OP47 SDP ( ANC), and TeletexB
OP47 Multi (ANC)) with caption text and V-chip information overlaid on the picture
(monitor mo
de) or on Status, Alarm, or E rror screens. There are also settings for
missing (incorrectly inserted) closed captioning.
Picture are
a
Support for standard and custom Safe Graticules for Picture displays for monitoring
for incorrect placements of graphics, logos. Two Safe Area graticules and Safe
Title grat
icules are supported.
Status scr
eens
Status scr
eens provide content status at a glance.
Physical measurements
(Option EY
E and PHY only) Verification and automatic measurement of the electrical
characteristics of the SDI physical layer. An Eye display lets you use the graticule or
voltage and time cursors to measure the waveform. A Jitter waveform display shows
jitter an
d jitter thermometers provide two independent measurements of jitter and
one of cable loss, and relates those measurements to defined alarm limits.
Error tra
cking
Configurable alarms and error logging.
Remote co
ntrol
Full remote control for complete installation flexibility.
x Waveform Rasterizers Quick Start User Manual
