Preface
Instrument Options
The W VR6020, WVR7020, and WVR7120 ship with support for monitoring standard definition (SD) serial digital signals. The
following options are available for purchase with the indicated instrument models. You c an verify which options are installed
on your instrument after power-up by pressing the CONFIG button and looking under the View HW/SW Option s submenu.
(See page 7, Connecting Power and Powering On/Off.)
Option
Instrument Description
DL WVR7020
WVR7120
Adds dual link (DL) support. DL allows for the monitoring of
dual link signals. Information from each input is combined and
shown on a single display. Supports all 10 bit and 12 bit YCbCr
and RGB formats. This option includes option H D.
SIM
WVR7120
Adds simultaneous input monitoring (SIM) support. SIM allows
for monitoring of two different input channels at the same time.
Input information is displayed as separate waveform displays in
two FlexVuTM tiles (either horizontally or vertically). Supports
SDI-SDI and SDI-Composite input combinations.
HD WVR7020
WVR7120
Adds support for high definition (HD) serial digital monitoring;
two HD-SDI inputs. This option included with Option DL.
CPS
WVR6020
WVR7020
WVR7120
Adds support for composite (CPS) analog video monitoring
(NTSC and PAL); two passive loop-through inputs; two
composite analog inputs.
AD WVR6020
WVR7020
WVR7120
Adds support for digital audio monitoring, and analog audio
and digital audio in embedded and AES/EBU formats; two sets
of six channels of analog audio inputs; eight channels analog
audio outputs.
DDE WVR7120
Adds option AD c apabilities, plus support for decoding and
monitoring Dolby Digital (AC-3) and Dolby E audio.
AVD WVR7120
Adds support for Audio/Video delay (AVD) measurement.
EYE WVR7120
Adds support for Eye pattern display, jitter m easurements, and
cable parameter measurements.
PHY WVR7120
Adds option EYE capabilities, plus support for jitter waveform
and automated eye measurements.
You can add any or all of the following service options to any instrument:
Option C3. Adds 3 years of Calibration Service.
Option C5. Adds 5 years of Calibration Service.
Option D1. Adds a Calibration Data Report.
Option D3. Adds 3 years of Calibration Data Report (when ordered with option C3).
Option D5. Adds 5 years of Calibration Data Report (when ordered with option C5).
Option R3. A dds 3 years of Repair Service (including the period under warranty).
Option R5. Adds 5 years of Repair Service (including period under warranty).
Waveform Rasterizers Quick Start User Manual xi
