Operating Your I
nstrument
To display and a
djust cursors
1. Choose a tile th
at is currently displaying
a waveform.
2. Press and hold the CURSOR button to
display the cursor menu and then select
the cursor s ty
le you want: Voltage,
Time,orVoltage + Time.(Oncethe
cursors are activated and the pop-up
menu is closed
, pushing CURSOR again
turns the cursors off.)
3. Pu sh the arrow keys to select the ac tive
cursor:
If Voltage or Time cursors are
displayed, p
ress any arrow key to
activate a cursor.
If Voltage + Time cursors are both
displayed, press either the up or
down arrow k
ey to select between
voltage cursors. Press either the left
or right arrow key to select between
thetimecur
sors.
4. Turn the GEN
ERAL knob to adjust the
selected cursor on the waveform. The
active cursor readout appears in yellow
withaknob
icon.
NOTE. To quickly center the active cursor
on screen, press and hold the SEL button.
5. Repeat ste
ps 3 and 4 to adjust the other
cursor.
6. Read the cursor measurement in the
Cursors readout.
NOTE. Usi
ng the % cursors is useful for
measuring risetimes.
34 Waveform Rasterizers Quick Start User Manual
